1996-01 Audi A4 1.8T Test Pipe 2002-05 Audo A4 1.8T Test Pipe 1998-05 Passat 1.8T Test Pipe (AU-EXH001P)

As the turbo begins to spin and build boost pressure, the vacuum pressure created before the turbo starts to increase as well. With more boost, this vacuum pressure increases exponentially. The factory turbo inlet hose sits right before the turbo and is made of flexible rubber. With vacuum, it starts to "collapse" into itself (imagine a full ballon getting the air sucked out). Thus, the inner diameter of the factory inlet hose starts to shrink and get smaller. The more boost pressure, the more vacuum is created in front of the turbo. This creates a big problem as at peak boost, the factory inlet hose's inner diameter is at its smallest (due to highest vacuum), however at peak boost, it needs to be at its largest size to feed air to the turbos. The turbo starts to choke as its having a more difficult time pulling air through it (due to the collapsing factory turbo inlet hose) and thus slows down the turbo spool time, negatively affecting throttle response and potentially decreasing top end power potential. With factory boost pressures, this is not big problem as the factory turbo inlet hose is designed to at least withstand the vacuum pressures produced. However, with increased boost pressures with chip upgrades and even turbo upgrades, this problem will begin to surface. On some instances, the factory turbo inlet hose may completely collapse and soffocate the turbo, causing the engine to run extremely rich and stall the engine. Evolution Racewerks' turbo inlet pipe (TIP) was designed to solve these issue completely. Made from 6061 aluminum metal (lightweight, yet strong) the diameter of the piping stays the same regardless of the vacuum pressures present and thus impossible to collapse. This ensures that there is sufficient airflow to the turbos, especially at peak boost levels where vacuum pressure is at its peak as well. The benefits? Faster spool times, increase throttle response and higher sustained power levels.

Features:

• Made from high grade 6061 aluminum piping
• 100% TIG welded
• Mirror polished finish
• Increase throttle response
• Increase turbo spool up
• Maintains ALL factory components
• Includes all hardware needed to install
• Limited Lifetime Warranty

Fitment:

• Audi A4 B5 1.8T with OEM MAF 96-01

Notes:

• Images used for marketing purpose only actual product may vary!
• This product is intended for OFF ROAD USE ONLY.
• Not legal for use on pollution controlled vechiles upon public highways.
• This item is not for sale, installation, or use on licensed vehicles in the state of California.
